Japanese Car Factory Options

Home  ⁄  HONDA  ⁄  ODYSSEY  ⁄  HONDA ODYSSEY EXCLUSIVE

Description
Model EXCLUSIVE
Chassis ID E-RA2
Release date 1995.12~
Base price in Yen (¥) 3,595,000
Body dimensions (L x W x H mm) 4750 x 1790 x 1750
Passenger compartment (L x W x H mm) 2810 x 1505 x 1285
Wheelbase (mm) 2830
Track front / rear wheels (mm) 1525/1540
Weight (kg) 1630
Body type MV 1Box
Number of seats / doors 6 / 5 door

Safety equipment
Driver's air bag Standard
Front passenger air bag Standard
Side airbags Not
ABS brakes Standard
TRC (traction control) Not
Safety belt pre-tensioner Not
Safety belt load limiter Not
Safety belts with automatic locking Standard
Child restraint points Not
Body reinforcement Standard
Brake assist Not
Body designed to absorb and disperse collision energy Not
EBD (electronic brakeforce distribution) Not
Anti theft device Not
Additional equipment No

Comfort
Air conditioner Dual air conditioning
Power windows Standard
Central locking Standard
Adjustable steering column length Not
Adjustable steering column height Standard
Cruise control Not
Leather steering wheel Standard
Leather seats
Power front seat Not
Power rear seat Not
Wood trim Standard
Sunroof ツイン
Alloy wheels 15 inches standard
Folding seat Not
Glass with UV filter Not
Privacy glass Standard
Engine
Series F22B
Type water cooling inline 4 cylinder SOHC 16-valves
Bore x stroke length (mm) 85.0x95.0
Engine size 2156cc
Compression ratio 8.8
Fuel injection system EFI (electronic fuel injection)
Maximum power 145ps(107kW)/5600rpm
Maximum torque 20.0kg m(196.1N m)/4600rpm
Aspiration Not
Fuel tank capacity (L) 60 l
Fuel type Regular unleaded gasoline
Fuel consumption (L / 100 km) ---

Steering and suspension
Steering Power assist equipped rack&pinion
Front suspension Double wishbone
Rear suspension Double wishbone
Front brake Disk
Rear brake disk
Front wheel 205/65R15 94S
Rear wheel 205/65R15 94S
Turning circle 5.7m

Gearbox
Number of speeds / type 4 speed automatic
Drive Full-time 4WD
LSD ----

Exterior equipment
Front fog lights Not
Rear fog lights Not
Xenon headlights Not
Additional front headlights Not
Front / rear spoiler Option / Option
Rear wiper Standard

Navigation, audio and video
Navigation system Standard
GPS CD
Audio AM/FM radio with CS player
CD player Not

LEGEND

Standard     Unknown    Optional
Gear ratios
CVT 1 2 3 4 5 6 7 8 REVERSE
2.736 1.566 1.081 0.731 2.047
Original factory colours
Other black
Other white
Other Purple
