Description
Model TSI R LINE
Chassis ID DBA-3CCZE
Release date 2015.7~
Base price in Yen (¥) 4,609,800
Body dimensions (L x W x H mm) 4785 x 1830 x 1470
Passenger compartment (L x W x H mm) ----x----x----
Wheelbase (mm) 2790
Track front / rear wheels (mm) 1580/1560
Weight (kg) 1460
Body type Sedan
Number of seats / doors 5 / 4 door

Safety equipment
Driver's air bag Standard
Front passenger air bag Standard
Side airbags Standard
ABS brakes Standard
TRC (traction control) Not
Safety belt pre-tensioner Standard
Safety belt load limiter Standard
Safety belts with automatic locking Standard
Child restraint points Not
Body reinforcement Not
Brake assist Standard
Body designed to absorb and disperse collision energy Not
EBD (electronic brakeforce distribution) Standard
Anti theft device Standard
Additional equipment ESP(エレクトロニック スタビリゼーション プログラム) DSR(ドライバー ステアリング リコメンデーション)

Comfort
Air conditioner Dual air conditioning
Power windows Standard
Central locking Standard
Adjustable steering column length Standard
Adjustable steering column height Standard
Cruise control Standard
Leather steering wheel Standard
Leather seats
Power front seat Standard
Power rear seat Not
Wood trim Not
Sunroof Option
Alloy wheels 18 inches standard
Folding seat split
Glass with UV filter Standard
Privacy glass Standard
Engine
Series CZE
Type inline 4 cylinder DOHC 16-valves IC-turbo
Bore x stroke length (mm) 74.5x80.0
Engine size 1394cc
Compression ratio 10.0
Fuel injection system 電子制御
Maximum power 150ps(110kW)/5000~6000rpm
Maximum torque 25.5kg m(250N m)/1500~3500rpm
Aspiration IC turbo
Fuel tank capacity (L) 59 l
Fuel type Unleaded premium gasoline
Fuel consumption (L / 100 km) ---

Steering and suspension
Steering Power assist equipped rack&pinion
Front suspension McPherson Strut (stabilizer attaching)
Rear suspension 4リンク (stabilizer attaching)
Front brake Ventilated disk
Rear brake disk
Front wheel 235/45 R18
Rear wheel 235/45 R18
Turning circle 5.4m

Gearbox
Number of speeds / type 7AT
Drive FF
LSD ----

Exterior equipment
Front fog lights Standard
Rear fog lights Standard
Xenon headlights Not
Additional front headlights Not
Front / rear spoiler Standard / Not
Rear wiper Not

Navigation, audio and video
Navigation system Standard
GPS メモリータイプ
Audio AM/FMラジオ
CD player 単装

LEGEND

Standard     Unknown    Optional

Gear ratios
CVT 1 2 3 4 5 6 7 8 REVERSE
3.500 2.086 1.342 0.933 0.973 0.777 0.653 3.722
Original factory colours
Other black
Pure White
Other Navy blue
Other Cyan
Other Silver
Other Red
Other Pearl
