Description
Model FX LIMITED II
Chassis ID DBA-MH23S
Release date 2009.10~
Base price in Yen (¥) 1,155,000
Body dimensions (L x W x H mm) 3395 x 1475 x 1660
Passenger compartment (L x W x H mm) 1975 x 1295 x 1275
Wheelbase (mm) 2400
Track front / rear wheels (mm) 1295/1290
Weight (kg) 830
Body type Light RV
Number of seats / doors 4 / 5 door

Safety equipment
Driver's air bag Standard
Front passenger air bag Standard
Side airbags Not
ABS brakes Option
TRC (traction control) Not
Safety belt pre-tensioner Standard
Safety belt load limiter Standard
Safety belts with automatic locking Standard
Child restraint points Standard
Body reinforcement Standard
Brake assist Option
Body designed to absorb and disperse collision energy 採用
EBD (electronic brakeforce distribution) Option
Anti theft device Standard
Additional equipment No

Comfort
Air conditioner Full Auto
Power windows Standard
Central locking Standard
Adjustable steering column length Not
Adjustable steering column height Standard
Cruise control Not
Leather steering wheel Standard
Leather seats
Power front seat Not
Power rear seat Not
Wood trim Not
Sunroof Not
Alloy wheels 14 inches standard
Folding seat split
Glass with UV filter Standard
Privacy glass Standard
Engine
Series K6A
Type water cooling inline 3 cylinder DOHC 12-valves
Bore x stroke length (mm) 68.0x60.4
Engine size 658cc
Compression ratio 10.5
Fuel injection system EFI (electronic fuel injection)
Maximum power 54ps(40kW)/6500rpm
Maximum torque 6.4kg m(63N m)/3500rpm
Aspiration Not
Fuel tank capacity (L) 30 l
Fuel type Regular unleaded gasoline
Fuel consumption (L / 100 km) ---

Steering and suspension
Steering Power assist equipped rack&pinion
Front suspension McPherson Strut type Coil spring
Rear suspension ITL
Front brake Disk
Rear brake Drum
Front wheel 155/65R14 75S
Rear wheel 155/65R14 75S
Turning circle 4.4m

Gearbox
Number of speeds / type 4 speed automatic
Drive FF
LSD ----

Exterior equipment
Front fog lights Not
Rear fog lights Not
Xenon headlights Not
Additional front headlights Not
Front / rear spoiler Standard / Standard
Rear wiper Standard

Navigation, audio and video
Navigation system Not
GPS None
Audio AM/FMラジオ
CD player 単装

LEGEND

Standard     Unknown    Optional

Gear ratios
CVT 1 2 3 4 5 6 7 8 REVERSE
2.914 1.525 1.000 0.725 2.642
Original factory colours
Other black
Other Purple
Other Ashes
Other Cyan
Silver metallic
Pearl White
